Nanovia PETG CF (carbon fiber reinforced) - 2.85 mm - 2kg
Ref. naptgcf2200bk
The Nanovia PETG CF filament is a PETG-based filament reinforced with carbon fiber. It is ideal for manufacturing mechanical and functional parts.
Printable on most FDM 3D printers, it can be used both indoors and outdoors.
Available in a 2kg format.
€152.90 excl. VAT
Our experts are at your service to answer your questions and provide advice at info@polyfab3d.com.
Delivery within 48/72 hours
Order before 1pm. Same day shipping
Free delivery
Free delivery near you from €69.90
Premium support
Our teams are on hand to answer all your questions
Over 3500 products
A wide choice of products from the biggest brands
Nanovia PETG-CF: High-Quality 3D Filament
Nanovia PETG-CF is a technical filament combining PETG and carbon fiber, developed by the French manufacturer Nanovia. This high-performance material enables the printing of robust, durable mechanical parts.
Thanks to its reinforced structure, Nanovia PETG-CF offers a solid, low-brittle filament that is also easy to post-process.
Ideal for printing technical parts requiring high mechanical strength and excellent dimensional stability.
Key Advantages of Nanovia PETG-CF
- Dimensional control: Print functional parts with excellent dimensional accuracy.
- High structural strength: The high carbon fiber content gives outstanding strength, ideal for mechanical and structural parts.
- Ease of printing: Prints like standard PETG, with reduced warping and excellent adhesion.
Technical Characteristics of Nanovia PETG-CF Carbon Fibers
- Median fiber length: 251 μm
- Average diameter: 7 ±2 μm
- Fibers > 100 μm: 70%
- Population: 9×106 units/g filament
⚠️ Warning: This abrasive filament wears brass nozzles quickly (~10h printing).
We recommend using reinforced nozzles (hardened steel, ruby, etc.) with a minimum diameter of 0.5mm.
- 🎯 We collaborate with businesses.
- 📦 Stock in Europe
- 🚚 Ships within 24 hours
- 🔐 Secure payments
- 🔙 14 days to change your deww
- 📱 Need advices ? Contact technical support
Specifications for Nanovia PETG CF (carbon fiber reinforced) - 2.85 mm - 2kg
Technology / Product
- Technology
- FDM
- Material
- PETG
- Visual Appearance
- Opaque, Mat, Carbon
- Made in France
- Yes
- Diameter
- 2.85 mm
- Sensitivity to humidity
- Low
- Application
- Aesthetics, Prototyping, Production, Functional part
- Odour
- Yes
- Harmful
- Yes
- Level of difficulty
- Novice
- Brand
- Nanovia
- Type of product
- 3D Filament
- Colour
- Black
- Net weight
- 2 kg
Technical values
- Glass transition temperature
- 85 °C
- Deflection temperature under load (1.8 MPa)
- 80 °C
- Charpy
- 20 kJ/m² of energy
- Resistors
- Mechanical engineering, Chemical
- Composite
- Carbon
- Tensile modulus
- 4700 Mpa
- Tensile yield strength
- 42 MPa
- Maximum elongation at break
- 2 %
- Density
- 1.08 g/cm3
Extrusion
- Nozzle type
- Steel, Ruby
- Type of consumable
- Non-proprietary filament (open system)
- Min. plateau temperature
- 80 °C
- Max. tray temperature
- 100 °C
- Min. extrusion temperature
- 200 °C
- Max. extrusion temperature
- 240 °C
- Min. speed
- 20 mm/s
- Max. speed
- 50 mm/s
- Minimum nozzle diameter
- 0.5 mm
- Bowden compatibility
- Yes
- Warping sensitivity
- Low
- AMS compatible
- No
Specific equipment
- Closed printing enclosure
- No
- Filtration
- HEPA, Coal
Installation / Prerequisites
- Type
- Filament on spool
- Box supplied
- Yes
- Coil material
- Plastic
