ABS AF Nanovia (aramid fiber reinforced) – 2.85 mm – 500 g
Ref. naabsaf2050bk
Nanovia’s aramid fiber (Kevlar®) reinforced ABS is ideal for 3D printing tooling thanks to its superior impact resistance and easier printing compared to standard ABS!
€48.15 excl. VAT
VAT at 20%, which is €57.78 TTC including tax.
Our experts are at your service to answer your questions and provide advice at info@polyfab3d.com.
Delivery within 48/72 hours
Order before 1pm. Same day shipping
Free delivery
Free delivery near you from €69.90
Premium support
Our teams are on hand to answer all your questions
Over 2000 products
A wide choice of products from the biggest brands
Nanovia ABS AF – Kevlar®-Reinforced ABS (2.85 mm)
Nanovia ABS AF is a technical ABS filament reinforced with aramid fibers (Kevlar®), ideal for functional parts, tools, and industrial use. This 2.85 mm version is compatible with Ultimaker printers and similar systems.
Kevlar® reinforcement provides excellent impact and wear resistance, with easier printing than standard fiber composites. Designed for reliable, low-warp printing even on open printers.
Key Features
- 2.85 mm diameter – Ultimaker-compatible
- Kevlar® reinforcement – impact & friction resistant
- Low warping, strong adhesion
- Less abrasive than carbon/glass fibers
- Outdoor-capable (paint finish recommended)
Print Settings
- Nozzle: ≥ 0.5 mm hardened
- Temperature: 240 °C
- Bed: 100 °C
- Adhesion: Magigoo or equivalent
Storage & Safety
- Keep dry – store with desiccant or in drybox
- Drying: 60 °C for 4h if exposed to moisture
- Printing environment: use ventilated or enclosed setup
- 🎯 We collaborate with businesses.
- 📦 Stock in Europe
- 🚚 Ships within 24 hours
- 🔐 Secure payments
- 🔙 14 days to change your deww
- 📱 Need advices ? Contact technical support
Specifications for ABS AF Nanovia (aramid fiber reinforced) – 2.85 mm – 500 g
Technologie / Produit
- Technology
- FDM
- Material
- ABS
- Visual aspect
- Opaque, Mat, Smooth alcohol
- Made in France
- Yes
- Diameter
- 2.85 mm
- Sensitivity to humidity
- Low
- Application
- Prototyping, Production, Functional part
- Odour
- Yes
- Harmful
- Yes
- Level of difficulty
- Intermediate
- Brand
- Nanovia
- Type of product
- 3D Filament
- Net weight
- 500 g
Valeurs techniques
- Glass transition temperature
- 101 °C
- Deflection temperature under load (1.8 MPa)
- 90 °C
- Charpy
- 5.2 kJ/m² of energy
- Resistors
- Mechanical engineering
- Composite
- Kevlar
- Tensile modulus
- 2400 Mpa
- Maximum elongation at break
- 7.5 %
- Density
- 1.05 g/cm3
- Shore hardness
- 77 D
Extrusion
- Nozzle type
- Tempered steel, Ruby
- Type of consumable
- Non-proprietary filament (open system)
- Min. plateau temperature
- 90 °C
- Max. tray temperature
- 110 °C
- Min. extrusion temperature
- 250 °C
- Max. extrusion temperature
- 270 °C
- Min. speed
- 50 mm/s
- Max. speed
- 70 mm/s
- Minimum nozzle diameter
- 0.5 mm
- Bowden compatibility
- Yes
- Warping sensitivity
- Average
Équipements spécifiques
- Closed printing enclosure
- Yes
- Filtration
- HEPA, Coal
Installation / Prérequis
- Type
- Filament on spool
- Box supplied
- Yes
- Coil material
- Plastic
