PETG CF Nanovia (carbon fiber reinforced) - 1.75 mm - 500g
Ref. naptgcf1050bk
Nanovia PETG CF is a carbon fiber-reinforced PETg filament, ideal for producing mechanical and functional parts.
Compatible with most FDM 3D printers, it can be used both indoors and outdoors.
€40.25 excl. VAT
Our experts are at your service to answer your questions and provide advice at info@polyfab3d.com.
Delivery within 48/72 hours
Order before 1pm. Same day shipping
Free delivery
Free delivery near you from €69.90
Premium support
Our teams are on hand to answer all your questions
Over 3500 products
A wide choice of products from the biggest brands
PETG-CF Nanovia: Carbon Fiber Reinforced Technical Filament
Nanovia PETG-CF is a high-performance composite filament made from PETG and carbon fibers. Developed by the French manufacturer Nanovia, it is ideal for 3D printing strong and durable mechanical parts.
With its advanced formulation, PETG-CF offers excellent stiffness and dimensional stability, while remaining less brittle than many technical filaments. It is perfect for printing functional or structural components under high mechanical stress.
Why choose Nanovia PETG-CF?
High dimensional accuracy: Ideal for technical functional parts requiring tight tolerances.
Excellent mechanical strength: The high carbon fiber content makes it suitable for structural elements.
Easy to print: Prints like standard PETG, with low warping and strong adhesion to the bed.
Carbon Fiber Properties
- Median length: 251 μm
- Fiber diameter: 7 ± 2 μm
- Fibers > 100 μm: 70%
- Fiber count: 9 × 106 units / g of filament
⚠️ This filament is abrasive and will quickly wear brass nozzles (~10 hours). Use a hardened steel or ruby nozzle with a minimum diameter of 0.5 mm.
- 🎯 We collaborate with businesses.
- 📦 Stock in Europe
- 🚚 Ships within 24 hours
- 🔐 Secure payments
- 🔙 14 days to change your deww
- 📱 Need advices ? Contact technical support
Specifications for PETG CF Nanovia (carbon fiber reinforced) - 1.75 mm - 500g
Technology / Product
- Technology
- FDM
- Material
- PETG
- Visual Appearance
- Opaque, Mat, Carbon
- Made in France
- Yes
- Diameter
- 1.75 mm
- Sensitivity to humidity
- Low
- Application
- Aesthetics, Prototyping, Production, Functional part
- Odour
- Yes
- Harmful
- Yes
- Level of difficulty
- Novice
- Brand
- Nanovia
- Type of product
- 3D Filament
- Colour
- Black
- Net weight
- 500 g
Technical values
- Glass transition temperature
- 85 °C
- Deflection temperature under load (1.8 MPa)
- 80 °C
- Charpy
- 20 kJ/m² of energy
- Resistors
- Mechanical engineering, Chemical
- Composite
- Carbon
- Tensile modulus
- 4700 Mpa
- Tensile yield strength
- 42 MPa
- Maximum elongation at break
- 2 %
- Density
- 1.08 g/cm3
Extrusion
- Nozzle type
- Steel, Ruby
- Type of consumable
- Non-proprietary filament (open system)
- Min. plateau temperature
- 80 °C
- Max. tray temperature
- 100 °C
- Min. extrusion temperature
- 200 °C
- Max. extrusion temperature
- 240 °C
- Min. speed
- 20 mm/s
- Max. speed
- 50 mm/s
- Minimum nozzle diameter
- 0.5 mm
- Bowden compatibility
- Yes
- Warping sensitivity
- Low
- AMS compatible
- No
Specific equipment
- Closed printing enclosure
- No
- Filtration
- HEPA, Coal
Installation / Prerequisites
- Type
- Filament on spool
- Box supplied
- Yes
- Coil material
- Plastic
